15
15.1 Device Overview
212 Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
15.1 Device Overview
The digital fault recorder SIMEAS R-PMU is available in two housing versions:
ZE 8/16
This version (10-inch housing) is equipped with one data acquisition unit (DAU).
ZE 32/64
This version (19-inch housing) provides space for up to 4 data acquisition units.
Data acquisition units
Different data acquisition units can be used for a flexible assignment of current, voltage and DC
variable inputs:
 VCDAU (4 voltage and 4 current channels, 16 binary channels)
 VDAU (8 voltage channels, 16 binary channels)
 CDAU (8 current channels, 16 binary channels)
 DDAU (8 DC channels, 16 binary channels)
 BDAU (32 binary channels)
