14
14.3 Extending the Existing Hardware
198 Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
14.3 Extending the Existing Hardware
General
The following ways of adjusting or extending the hardware of existing SIMEAS R-PMU systems
are distinguished:
Extending a SIMEAS R-PMU by additional data acquisition modules
Replacement of data acquisition modules of different types
Extending a SIMEAS R-PMU by external communication components.
Note
The procedure for different extension methods is described below.
WARNING
Warning about dangerous voltages in electrical equipment after turning off the device.
Nonobservance of the safety instructions means that death, heavy
injuries or considerable material damages can occur.
• Make sure that the device is de-energized before opening the housing! Please bear in mind
that any process variables provided must also be separated from the device.
