16.1 Technical Data of the SIMEAS R-PMU
245Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
16.1.4 Analog and Binary Inputs and Outputs
Slot 2
(ZE 8/16, one DAU) Can be equipped as per Table 16-2
Slots 2to5
(ZE 32/64, up to four DAUs) Can be equipped as per Table 16-2
Measured value processing
A/D converter: 16 bit, 64 times oversampling, 92 dB dynamic range
Table 16-2 Configuration options
VCDAU 8 analog (4 current/4 voltage) and 16 binary
channels
VDAU 8 analog (8 voltage) and 16 binary channels
CDAU 8 analog (8 current) and 16 binary channels
DDAU 8 analog (8 current DC ±20 mA or
8 voltage DC ±1 V or DC ±10 V)
and 16 binary channels
BDAU 32 binary channels
Table 16-3 VCDAU, VDAU and CDAU
Nominal
frequency
Sampling
frequency
Frequency range Samples/cycle
50 Hz 9,600 Hz 25 Hz to 60 Hz 192
60 Hz 11,520 Hz 30 Hz to 70 Hz 192
Table 16-4 DDAU
Nominal
frequency
Sampling
frequency
Frequency range Samples/cycle
50 Hz 9,600 Hz 0 Hz to 500 Hz 192
60 Hz 11,520 Hz 0 Hz to 500 Hz 192
