16.1 Technical Data of the SIMEAS R-PMU
243Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
Power failure bridging
- without battery
- with battery
Power failure bridging over 10 minutes if all functions are in operation
and the battery is fully charged
Power input
ZE 8/16
8 analog / 16 binary channels DC 24 V to DC 60 V 20 W
DC 110 V to DC 250 V 18 W
AC 115 V to AC 230 V 30 VA
ZE 32/64
32 analog / 64 binary channels DC 24 V to DC 60 V 45 W
DC 110 V to DC 250 V 40 W
AC 115 V to AC 230 V 70 VA
Table 16-1 Power failure bridging times acc. to IEC 60255-11/1979 and VDE 0435 part 303/
09.84
Power failure bridging time ZE 8/16 ZE 32/64
for DC 24 V
≥ 400 ms ≥ 150 ms
for DC 60 V
≥ 450 ms ≥ 170 ms
for DC 110 V
≥ 500 ms ≥ 180 ms
for DC 250 V
≥ 700 ms ≥ 200 ms
for AC 115 V
≥ 500 ms ≥ 200 ms
for AC 230 V
≥ 800 ms ≥ 350 ms
