18.2 Data Acquisition Units (DAU)

266 Digital Fault Recorder, SIMEAS R-PMU, Manual

E50417-H1076-C360-A5, Release 10.2012

With binary signals, the sampling frequency for all DAU types is consistently 2 000 Hz.

Frequency accuracy at f

±5 Hz

VCDAU: 5 mHz

VDAU: 5 mHz

CDAU: 5 mHz

Table 18-9 Sampling frequency

DAU type Rated

frequency

Frequency

range

Sampling

frequency

Sample values

per period

VCDAU; VDAU; CDAU 50 Hz 25 Hz to 60 Hz 9,600 Hz 192

DDAU 50 Hz 0 Hz to 500 Hz

VCDAU; VDAU; CDAU 60 Hz 30 Hz to 70 Hz 11,520 Hz

DDAU 60 Hz 0 Hz to 500 Hz
