Description of the blocks
4.7 MMRevDhl motor block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
207
● In the case of blocks with operator control or monitoring functions (for example,
faceplates), these signals are identified in the faceplate with the status for the simulation
as follows:
● The group status of the block is displayed in the status bar of the block icon and of the
operator block with the simulation status as follows:
● The interlocking functions of the block are activated in accordance with the input
parameter
BypProt = 0 or deactivated BypProt = 1.
● Auxiliary values (e.g. UserAna1) cannot be simulated.
● When the control function of the block can be manipulated, the read-back and feedback
values (for example,
FbkFwd) are adjusted according to the manipulation of the control
settings
The monitoring function can be released or blocked via the operator in the faceplate.
The
Monitor parameter indicates whether the feedback for the monitoring function is
activated:
●
Monitor = 1 (default): Monitoring function ON
●
Monitor = 0: Monitoring function OFF
If the block is in Local mode, no check is made for monitoring errors.
If the "Forward" / "Stop" command is output and no correct feedback signal is received within
the defined time (
MonTiDynamic), the block will issue an error signal (MonDynErr) and the
output signal will issue the "Stop" command.
The monitoring time is specified in seconds. If the monitoring time is less than the sampling
time, the monitoring time will be calibrated to the sampling time. The time can be entered in
the faceplate in the expanded command area in day-hour-minute-second format.
The function is not available in Out of Service mode.
Note
The monitoring functions are functions of the block.
pro nevertheless has its own functions for monitoring the on/off operations and
the switching state of the motor.
The monitoring functions of the block can come into conflict with monitoring functions
configured in SIMOCODE
pro under certain conditions.
Once 'monitor' function is activated, the current monitoring time
will be shown at CurrMon
output parameter and the same will be shown in preview faceplate.
