Siemens SIMOCODE pro User Manual

Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
163
4.4.7
Status information
The status information is communicated to WinCC for display in the faceplates.
Table 4- 71 Status information – MMMeas
Status1
Bit
Description
0
Occupied
1 BatchEn
3
1 = OOS Mode
4 OosLi Active
6 0 = On Mode
1 = Local Mode
8
Temperature Module 1 Available Status
9
Temperature Module 2 Available Status
10
Earth Fault Module EM, EM+ Available Status
11
Voltage Module Available Status
12
Current Module Available Status
13
Analog Module 1 Available Status
14
Analog Module 2 Available Status
15
Temperature Module (TM1) - 2 Sensors
16
Temperature Module (TM1) - 3 Sensors
17
Analog Module (AM1) - 2 Active Units
18
Analog Module (AM1) - 3 Active Units
19
Temperature Module (TM2) - 2 Sensors
20
Temperature Module (TM2) - 3 Sensors
21
Analog Module (AM2) - 2 Active Units
22
Analog Module (AM2) - 3 Active Units
23
Voltage Display Phase/Line to Line
28
Group Error
29 MsgLock Enabled
30 0 = Disable RdDataOp button on Rack Fault & No trigger to RdDataOp from
Faceplate
1 = Enable RdDataOp button
31 Slv_Typ
0 = PROFIBUS
1 = PROFINET
Status2
Bit
Description
0
Last Successful Readdata Timestamp
1-31
Reserved

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
