Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
160 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Table 4- 68 Assignment of PZDInxx to the feedback from SIMOCODE pro
Basic unit type SIMOCODE pro
byte
Cyclic
send data
PZDInxx
BU 1 4–5 Values
parameterized in
SIMOCODE ES
PZDIn45
6–7 PZDIn67
8–9 PZDIn89
SIMOCODE pro
PROFINET:
BU 3
10–11 – PZDIn10
12–13 PZDIn12
14–15 PZDIn14
16–17 PZDIn16
18–19 PZDIn18
4.4.4.3 Write analog output
The analog output can be written cyclically to the SIMOCODE pro device.
With the parameter
LiOp, you can parameterize whether the operator-controllable input
AMOutIn, AM2OutIn (LiOp = FALSE) or the interconnectable input AMOutLi, AM2OutLi is used
(LiOp = TRUE).
If the interconnectable input is selected, the operator-controllable input is deactivated.
4.4.4.4 Acyclic reading
Reading the data record 94 is either triggered using the interconnectable input parameter
RdDataLi, in the OS when selecting the faceplate, or by OS operation (RdDataOp = 1).
The data that is read is normalized and sent to the output parameters.
If an error occurs, the values are set to zero and the output
RdErr = 1 is set.
