Siemens SIMOCODE pro User Manual

Description of the blocks
4.6 Block for timestamping MMLog
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
185
4.6.4
Logbook function
The error buffer is available for SIMOCODE pro C / S / V PROFIBUS and PROFINET.
The error buffer contains the tripping events and events that a SIMOCODE pro device has
saved.
A maximum of 21 messages are recorded and displayed in the Logbook view (Page 195).
Each message contains the following attributes:
Attributes
PROFIBUS devices
PROFINET devices
Tripping events
Output
LogId1
to
LogId21
Number of the message Number of the message
Output LogTm1 to LogTm21 Operating hours of the
device
Real-time stamp
1
Text of the message
Events
2
Output EnCktCls / EnCktOpn
Type of the message
Type of the message
Output ClsTmStmp / OpnTmStmp
Time stamp
Time stamp
Text of the message
1
Date and real time are logged, if there is a valid time that has been synchronized via an NTP clock
or set manually with SIMOCODE ES.
2
When using DM-F expansion modules with SIMOCODE pro V.
Data records
The values are read from the SIMOCODE pro device with the "RDREC" function. This
information is written to the output parameters.
No.
Data rec-
ord num-
ber
Read ac-
cess/write
access
Number
of bytes
Description
For
PROFIBUS
For
PROFINET
1
DS72
R
125
Read tripping event
Yes
Yes
2
DS73
R
165
Read event (DM-F)
Yes
Yes
3 DS76 R 193 Time stamp for tripping
event
No Yes
4 DS77 R 193 Time stamp for events
(DM-F)
No Yes
Note
The user can suppress the reading of these datarecords by selecting the Feature.Bit26 = 1.
In that case, the data is not read from the device. Also the Logbook view button will be
disabled at the Faceplates.
