Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
131
4.3.19
Status information
The status information is communicated to WinCC for display in the faceplates.
Table 4- 40 Status information – MMOprtn
Status1
Bit
Description
0
Occupied
1 BatchEn
2 0 = PROFIBUS
1 = PROFINET
3
OosAct.Value
4
OosLi active
5 0 = Man Active
1 = Auto Active
6
1 = Local Active
7
1 = Command fast forward / closed / reverse
8
1 = Motor stop
9
1 = Forward/Open Command
10
1 = Fast reverse Command
11
1 = Reverse Command
12
1 = Mode selector S1 on
13
1 = Reset on
14 0 = Test function inactive, (PIO)
1 = Test function active
15 0 = Emergency start inactive (PIO)
1 = Emergency start active
16 0 = Trip Reset inactive, (PIO)
1 = Trip Reset active
17
1 = Feedback fast forward / reverse on / close positioner
18 1 = Status – Motor OFF
19
1= Feedback forward ON / motor ON / positioner open
20 1 = Event – overload
21
1 = Status – change-over pause active
22 Status – Remote:
0 = Local Operation
1 = REMOTE Operation
23
1 = Status – General fault
24
1 = Status – General warning
25
1 = Feedback fast reverse / open positioner
26
1 = Feedback reverse on / close positioner
27
1 = Status – Interlocking time active
28 1 = Group error
0 = No error
29
MsgLock enabled
