Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
158 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
4.4.4.1
Read measured values
InputMode
The PZDInxx inputs are assigned to the ModeInxx parameter inputs. These determine
whether the measured values are read acyclically from data records (ModeInxx = 0) or
Cyclically updated (ModeInxx <> 0) through Process image wiring.
Measured values for SIMOCODE pro devices
Table 4- 64 Measured values for SIMOCODE pro devices
ModeInxx
Meaning
0
Measured value is read from data record.
Cyclic measured values:
1
Maximum current I_max
2 Current I_L1
3
Current I_L2
4 Current I_L3
5
Phase unbalance
6
Thermal memory
7
Time to trip
8
Cooling-down period
9
Last trip current
10
Max. temperature
11
Temperature 1
12
Temperature 2
13
Temperature 3
14
Voltage U_L1
15
Voltage U_L2
16
Voltage U_L3
17
AM – input 1
18
AM – input 2
19
Power factor
20
Active power
1
21 Apparent power
1
28
EM – ground fault current
29 EM – last ground fault trip current
30
AM Input 3
31
AM2 Input 3
1
If the active power or the apparent power should be read in cyclically, two consecutive inputs have
to be configured with
ModeInxx = 20 and ModeInxx = 21 respectively because the active power
and apparent power occupy a double word in SIMOCODE pro.
