Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
159
Additional Measured values for SIMOCODE pro PROFINET devices
Table 4- 65 Additional Assignment of ModeInxx for SIMOCODE pro PROFINET
Modexxxx
Meaning
0
Measured value is read from data record.
Cyclic measured values:
22
TM2 – max. temperature
23
TM2 – temperature 1
24
TM2 – temperature 2
25
TM2 – temperature 3
26
AM2 – input 1
27
AM2 – input 2
Assignment to the SIMOCODE pro basic units
The table shows the assignment of the inputs PZDInxx and Mode to the basic unit types.
Table 4- 66 Assignment to the basic units
Basic unit type
( BUTyp parameter)
Input word PZDInxx
Input ModeInxx
BU 1 PZDIn45
PZDIn67
PZDIn89
ModeIn45
ModeIn67
ModeIn89
BU 2
not available
not available
SIMOCODE pro PROFINET:
BU 3
PZDIn10
PZDIn12
PZDIn14
PZDIn16
PZDIn18
ModeIn10
ModeIn12
ModeIn14
ModeIn16
ModeIn18
4.4.4.2
Assignment of the cyclic process image
The IO Controller sends cyclic receive data to SIMOCODE pro. The SIMOCODE pro device
returns cyclic send data as a reply.
Table 4- 67 Assignment of
PZDOutxx
to the
analog value output
Basic unit type
SIMOCODE pro
byte
Cyclic receive data
PZDOutxx
BU 1
2–3
1
Analog value 1
PZDOut23
SIMOCODE pro
PROFINET:
BU 3
4–5 Analog value 2 PZDOut45
1
If the basic unit type 1 uses bytes 2 and 3 of the cyclic receive data, bytes 4 to 9 of the cyclic send
data can be additionally assigned.
