Description of the blocks
4.2 Diagnostics block MMDiag
SIMOCODE pro PCS 7 Library V9.0
96 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Auxiliary values
Table 4- 8 Structure of the auxiliary values ALARM_8P
Message No.
Auxiliary
value
Block parameters
Meaning
1
1
Subn1Id
ID of the primary subnet
2 2
Subn2Id
ID of the redundant subnet
3
3
Rack_No
Rack number
4
4
Slot_No
Slot number
5
5
ExtVa105
Auxiliary value 5, user-definable
6
6
ExtVa106
Auxiliary value 6, user-definable
7
7
ExtVa107
Auxiliary value 7, user-definable
8
8
ExtVa108
Auxiliary value 8, user-definable
9
9
ExtVa109
Auxiliary value 9, user-definable
10
10
ExtVa110
Auxiliary value 10, user-definable
The MsgStat1, MsgAckn1, and MsgErr1 parameters transfer the following information:
Message status
Message error
Message acknowledgment status
4.2.4
Driver generator
The "Generate Module Driver" function automatically inserts the MMDiag block into the
following organization blocks within the run sequence:
OB1 (cyclic program)
OB40 (process alarm)
OB82 (diagnostics alarm)
OB83 (pull/plug alarm)
OB85 (program execution error)
OB86 (rack fault)
OB100 (warm restart)
The block is inserted behind the OB_DIAG1 / OB_DIAG1_PN block in the CFC chart.
The
Rack_No, Slot_No, SubSlot_No, SubAddr, DAddr, LAddr, Subn1Id, Subn2Id and SubN_Typ
inputs are configured via the information from HW Config.
