Siemens SIMOCODE pro User Manual

SIMOCODE pro PCS 7 Library V9.0
38 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Templates
2
2.1
Overview of the templates, control functions and blocks
The templates from the SIMOCODE pro PCS 7 Library V9.0 are templates that you can
adopt unchanged to implement control functions in your project. The templates thus simplify
the engineering for configuring the blocks and they support their problem-free functioning.
You can also modify the templates or create completely new ones. The interconnections that
must then be created manually can be found in the available templates.
Templates for the control functions
The table below assigns the possible control functions to the associated template:
Table 2- 1 Templates for the control functions
No.
Control function
Template
APL blocks
SIMOCODE
blocks
1
Overload relay
OvlRly (Page 42)
FbSwtMMS
MMOprtn
1
MMMeas
MMStat
MMLog
2 Direct starter Direct (Page 43) MotL
1
Event16Ts
FbSwtMMS
3 Reversing starter Reverse (Page 44) MotRevL
1
Event16Ts
FbSwtMMS
4 Circuit breaker MCCB (Page 45) MotL
1
Event16Ts
FbSwtMMS
5 Star-delta starter StarDel (Page 46) MotL
1
Event16Ts
FbSwtMMS
6 Star-delta reversing starter RevStarDel (Page 47) MotRevL
1
Event16Ts
FbSwtMMS
7 Dahlander Dahland (Page 48) MotSpdL
1
Event16Ts
FbSwtMMS
8 Dahlander reversing starter RevDahl (Page 49) Event16Ts
FbSwtMMS
MMRevDhl
1
MMOprtn
1
MMMeas
MMStat
MMLog
9 Pole-changing starter PoleChng (Page 50) MotSpdL
1
Event16Ts
FbSwtMMS
MMOprtn
1
MMMeas
MMStat
MMLog
