Siemens SIMOCODE pro User Manual

Description of the blocks
4.7 MMRevDhl motor block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
215
Message block MsgEvId2
Table 4- 101 Output messages
Message block
Message
No.
Block parameters
Message text
Message
class *
MsgEvId2
1 ExtMsg4 ** $$BlockComment$$ MMOprtn Group Warn-
ing : @1W%t#MMOprtn_WRN@
S
2 ExtMsg5 ** $$BlockComment$$ MMOprtn Group Fault :
@2W%t#MMOprtn_TRP@
S
3 ExtMsg6 ** $$BlockComment$$ MMOprtn Control Sys-
tem Fault
S
4
ExtMsg **
$$BlockComment$$ MMOprtn Warning I>
S
5
ExtMsg8 **
$$BlockComment$$ MMOprtn Warning I<
S
6
ExtMsg9 **
$$BlockComment$$ MMOprtn Trip I>
S
7
ExtMsg10 **
$$BlockComment$$ MMOprtn Trip I<
S
8
ExtMsg11 **
$$BlockComment$$ MMOprtn Test Position
S
* S = AS, OS process control fault
** User-definable message
Table 4- 102 Structure of the auxiliary values ALARM_8P
Message No.
Auxiliary
value
Block parameters
Meaning
1
1
SarBatchName
Name of batch
2
2
SdwStepNoLoc
Step number
3
3
SdwBatchId
Identification number of the batch
4
4
ExtVa204
External value 4, user-definable
5
5
ExtVa205
External value 5, user-definable
6
6
ExtVa206
External value 6, user-definable
7
7
ExtVa207
External value 7, user-definable
8
8
ExtVa208
External value 8, user-definable
The MsgStat2, MsgAckn2 and MsgErr2 parameters transfer the following information:
● Message status
● Message error
● Message acknowledgment status
