Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
246 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
Curr_WL
INT
0
Warning level low 0…1020%
BatchEn BOOL FALSE Enable Remote Operation of Controller by Batch
Recipe
BatchID
DWORD
16#00
Current Batch ID (number)
BatchName
STRING
–
Current batch name
StepNo
DWORD
16#00
Batch step number
Occupied
BOOL
FALSE
Occupied by Batch
ExtMsg1 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 1
ExtMsg2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 2
ExtMsg3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 3
ExtMsg4 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 4
ExtMsg5 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 5
ExtMsg6 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 6
ExtMsg7 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 7
ExtMsg8 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 8
ExtVa104
ANY
–
External value 4
ExtVa105
ANY
–
External value 5
ExtVa106
ANY
–
External value 6
ExtVa107
ANY
–
External value 7
ExtVa108
ANY
–
External value 8
ExtVa109
ANY
–
External value 9
ExtVa110
ANY
–
External value 10
ExtVa206
ANY
–
External value 6 (MsgEvID2)
ExtVa207 ANY – External value 7 (MsgEvID2)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
