Parameter
A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
274 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
LocalLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Local Mode: Local Operation by Field Signal
LocalOp BOOL FALSE 1 = Local Mode: Local Operation by Operator
MS_RelOp BOOL FALSE Operator input for MS Release, 1: MS release require-
ment
OosOp
BOOL
FALSE
1 = Oos Mode: Oos Mode by Operator
OosLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Oos Mode: Oos Mode by Field Signal
FFwdLocal STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Start Local: Field Fast Forward Start Signal
FwdLocal STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Start Local: Field Forward Start Signal
StopLocal STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Stop Local: Field Stop Signal
RevLocal STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Start Local: Field Reverse Start Signal
FRevLocal STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Start Local: Field Fast Reverse Start Signal
LocalSetting
INT
0
Local Mode Behavior
FbkFFwd STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Fast Forward:
0 = Stop
1 = Run
FbkFwd STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Forward:
0 = Stop
1 = Run
FbkRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Reverse:
0 = Stop
1 = Run
FbkFRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Fast Reverse:
0 = Stop
1 = Run
