4.6 Interfaces and terminals
4-100
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) -- 05/2008 Edition
Note
In order to clearly indicate potential hazards due to voltages at the terminals,
the warning plate WS--2K (Order No. 1004513) can be ordered at the following
address.
Phoenix Contact GmbH & Co. KG
Flachsmarktstr. 8
32825 Blomberg
Germany
Tel.+495235300
Fax +49 5235 3 1200
http://www.phoenixcontact.com
Table 4-8 Terminals types and connecting cable, power modules
Terminal type
Designation Connecting cable [mm
2
]
Minimum Maximum
1 PC 5/3STF--7.62 GY 0.2 6
2 HDFK 10 0.5 16 (for rigid cables)
10 (for flexible cables)
3 HDFK 50 16 (for rigid cables)
10 (for flexible cables)
50
4 UHV 95 35 95
5 UHV 150 50 150
Table 4-9 Using the terminal types in the power module
Type
6SN1 12j--1AA0j-- 0H
A
j
0A
A
j
0B
A
j
0C
A
j
0D
A
j
0L
A
j
0E
A
j
0F
A
j
0J
A
j
0K
A
j
6SN1 12j--1AB0j-- 0H
A
j
0A
A
j
0B
A
j
0C
A
j
1 X X X X X X X X
2 X
3 X X
4 X X
5 X
Reader’s note
For a description of DC link terminal adapter for two--tier configuration, see the
dimension drawing in Fig. 12-56.
