1.3.5 Engineering the SIMODRIVE 611 line supply infeed for
SIMODRIVE POSMO SI/CD
When calculating the charge limit of the SIMODRIVE line supply infeed mod-
ules, for charging the ”DC link” an equivalent capacitance for POSMO SI/CD
should be used for each unit depending on the pre--charging circuit of the line
supply infeed module.
The number of POSMO units connected to a line supply infeed module is lim-
ited as a result of the charge limits.
Table 1-2 Equivalent capacitance for charge limits
Line infeed modules
SIMODRIVE 611
POSMO SI/CD 9 A POSMO CD 18 A
5kW,10kW,16kW 600 µF 1100 µF
28 kW to 120 kW 1740 µF 2200 µF
Table 1-3 Line supply power POSMO SI/CD
Designation
Order number Power drawn [kW]
POSMO SI 6SN2460--2CF00--jGjj 1.6
6SN2463--2CF00--jGjj 2.3
6SN2480--2CF00--jGjj 2.7
6SN2483--2CF00--jGjj 4.0
6SN2500--2CF00--jGjj 4.4
POSMO CD 9 A 6SN2703--2Aj0j--0BA1 5.2
POSMO CD 18 A 6SN2703--2Aj0j-- 0 C A 1 10.3
Table 1-4 Charge limit (net), line supply infeed modules
Designation
Order number Charge limit
(net) [
µF]
Rated power
[
kW]
UI 5 kW/10 kW 6SN1 14j--1AB00--0BA1 1050 5
10/25 kW UI 6SN114j--1AA01--0AA1 5560 10
I/R 16 kW/21 kW 6SN114j-- 1 B j01--0BAj 5505 16
UI 28 kW/50 kW 6SN114j-- 1 A j01--0CAj 19010 28
I/R 36 kW/47 kW 6SN114j-- 1 B j02--0CAj 19010 36
I/R 55 kW/71 kW 6SN114j-- 1 B jAj-- 0 D A 1 17855 55
I/R 80 kW/131 kW 6SN1 14j--1BB00--0EA1 17855 80
I/R 120 kW/175 kW 6SN114j--1BB00--0FA1 15710 120
Charge limit (net) = charge limit -- DC link capacitance, infeed module
Example, I/R 80 kW: 17855 µF = 20000 µF -- 2145 µF
