Siemens SIMODRIVE 611 digital - Assignment of the Isolating Transformer to the UI Modules

7
05.01
7.3 Line supply fuses, transformers and main switch
7-217
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) -- 05/2008 Edition
7.3.4 Assignment of the isolating transformer to the UI modules
Table 7-9 Matching transformers with separate windings for 50 Hz/60 Hz line supplies
UI module
5kW
2)
UI module
10 kW
2)
UI module
28 kW
Nominal rated power [kVA] 8.2 15.7 47
Power loss, max. [W] 520 650 1200
Vector group YYn0 neutral point N can only be loaded with maximum 10%!
Short--circuit voltage uk [%] ≤ 10
Degree of protection to
DIN EN 60529 (IEC 60529)
S Degree of protection IP 00: V -- -- > O r d e r N o . 0
S Degree of protection IP 20: V -- -- > O r d e r N o . 8
S Degree of protection IP 23: V -- -- > O r d e r N o . 2
1)
Humidity rating EN 60721--3--3 Class 3K5 condensation and formation of ice excluded
Permiss. ambient temperature
S Operation _C
S Storage/transport _C
--25 to +40, for power derating up to +55
-- 2 5 t o + 8 0
Approx. weight for
S Degree of prot. IP 00 [kg]
S Degree of prot. IP 20/23 [kg]
55
65
70
95
200
216
Dim. (L x W x H) approx. [mm] 360 x 268 x 320 420 x 262 x 370 480 x 267 x 420
Max. conn., secondary [mm
2
] 6 6 35
Input voltage, 3--ph. 575 V -- 500 V -- 480 V AC ± 10%; 50 Hz -- 10% to 60 Hz + 10%
Rated input current [A] 10.5 20 58
Max. conn., primary [mm
2
] 6 6 35
Order No. according to Catalog
PD10
4AU36 95--0SB0V--0CN2 4AU39 95--0SA3V--0CN2 4BU47 95--0SC3V-- 0 C
Input voltage, 3--ph. 440 V -- 415 V -- 400 V AC ± 10%; 50 Hz -- 10% to 60 Hz + 10%
Rated input current [A] 12.5 23.5 69.5
Max. conn., primary [mm
2
] 6 16 35
Order No. according to Catalog
PD10
4AU36 95--0SB1V--0CN2 4AU39 95--0SA4V--0CN2 4BU47 95--0SC4V-- 0 C
Input voltage, 3--ph. 240 V -- 220 V -- 200 V AC ± 10%; 50 Hz -- 10% to 60 Hz + 10%
Rated input current [A] 25.5 47 138.5
Max. conn., primary [mm
2
] 6 16 70
Order No. according to Catalog
PD10
4AU36 95--0SB2V--0CN2 4AU39 95--0SA5V--0CN2 4BU47 95--0SC5V-- 0 C
1)
For degree of protection IP 23, a 10% power derating must be taken into account
2) Not degree of protection IP 20
Note
UI modules can be operated on TN line supplies from 360 V (with derating!) to
480 V without a matching transformer.
7L
i
ne Su
p
p
l
y
Connec
t
i
on05.08
