10
10-341
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
Connection Diagrams
Note
The following connection diagrams only show the terminal connections.
Further, external components are not completely shown. Refer to Chapter 8.
The following comments should be observed in the connection diagrams:
1. The jumper may only be removed in conjunction with the start inhibit.
2. Not available for unregulated infeed.
3. Connect with terminal 19 of the NE module.
4. Drive bus – round cable
5. Drive bus – ribbon cable
6. Drive bus – terminating connector
7. For an external pulsed resistor, remove jumper 1R/2R.
