8.16 VPM Voltage Protection Module
The Voltage Protection Module (VPM, voltage limiting module) is used with per-
manent–magnet induction motors with EMF of 580 V
eff
to 1.4 kV
eff
to limit the
DC link voltage at the converter in the event of a fault. If the line voltage fails at
maximum motor speed or if the drive converter pulses are canceled as a result
of the power failure, the synchronous motor regenerates at high voltage back
into the DC link.
The VPM detects a DC link voltage that is too high (>820 V) and short–circuits
the three motor supply cables. The power remaining in the motor is converted to
heat via the short circuit between the VPM and motor cables.
Table 8-6 Technical data VPM
Technical specifications VPM 120 VPM 200 VPM 200 Dynamik
Order No.: 6SN1113–1AA00–1JA 6SN1113–1AA00–1KA 6SN1113–1AA00–1KC
Type of voltage 3–phase pulsed AC voltage, EMF motor
Lower limit, DC link voltage 490 V DC
Inverter clock cycle frequency 3.2...8 kHz
Rated current Max. 120 A rms Max. 200 A rms
Permissible short–circuit current
Time range
0...10 ms
10...500 ms
500...2 min
2 min
Maximum
1500 A
255 A
90 A
0 A
Maximum
2000 A
600 A
200 A
0 A
Electrical separation Safe electrical separation between the signaling contact and the motor cables U, V, W
according to DIN VDE 0160/pr EN 50178, UL 508
Degree of protection to
EN 60529 (IEC 60529)
IP20
Humidity classification
according to
DIN EN 60721–3–3
Cl. 3K5 condensation and formation of ice excluded.
Low air temperature 0 °C
Permiss. ambient temperature
Storage and transport
Operation
–25...+55 °C
0...+55 °C
Cooler Air–cooled, free convection
Weight approx. 6 kg approx. 11 kg approx. 13 kg
Dimensions (W x H x D) [mm] 300 x 150 x 180 300 x 250 x 190 300 x 250 x 260
Connection U, V, W, PE
Torque
Cable cross–section
Cable entry
Screwed connection
Screw connection, 8 x M6
10 Nm
50 mm
2
∅ approx. 40 mm
2 x M50
Screw connection, 8 x M8
25 Nm
2 x 50 mm
2
∅ approx. 40 mm
4 x M50
Screw connection, 14 x M8
25 Nm
2 x 50 mm
2
∅ approx. 40 mm
4 x M50
Conn. X3 (signaling contact)
Cable cross–section
Cable entry
Screwed connection
Terminal, type 226–111 Wago
1.5 mm
2
∅ approx. 9 mm
M16
Terminal, type 226–111 Wago
1.5 mm
2
∅ approx. 9 mm
M16
