11
11-345
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) -- 05/2008 Edition
Spare Parts and Service
11.1 Fan
Notice
When replacing the fan, you must observe the ESD regulations.
Spare parts must always be replaced by properly trained personnel!
Fan replacement with spare parts is possible for the following modules:
Table 11-1 Fan replacement options
Designation
Order No. (MLFB) Module
width
[mm]
Fan spare parts
(Order No.)
I/R module, 16 kW
internal
6SN1 145--1BA01--0BAV
1)
100 6SL3162--0AB00--0AD0
I/R module, 16 kW
external
6SN1 146--1BB01--0BAV
1)
100
I/R module, 36 kW
internal
6SN1 145--1BA02--0CAV
1)
200 6SL3162--0AF00--0AA0
I/R module, 36 kW
external
6SN1 146--1BB02--0CAV
1)
200
PM module, 50 A,
internal
6SN1 123--1AA00--0CAV
1)
50 A5E00885796
PM module, 50 A,
external
6SN1 124--1AA00--0CAV
1)
50
PM module, 2x50 A,
internal
6SN1 123--1AB00--0CAV
1)
100 6SL3162--0AB00--0AD0
PM module, 2x50 A,
external
6SN1 124--1AB00--0CAV
1)
50 A5E00885796
Two units required
PM module, 80 A,
internal
6SN1 123--1AA00--0DAV
1)
100 6SL3162--0AB00--0AD0
PM module, 80 A,
external
6SN1 124--1AA00--0DAV
1)
100
PM module, 108 A,
internal
6SN1 123--1AA00--0LAV
1)
200 6SL3162--0AF00--0AA0
PM module, 108 A,
external
6SN1 124--1AA00--0LAV
1)
200
PM module, 160 A,
internal
6SN1 123--1AA00--0EAV
1)
200
PM module, 160 A,
external
6SN1 124--1AA00--0EAV
1)
200
1) as of Version ≥ 2
Replacement
options
11
