2 System Configuration
2
05.01
2.3 Motor selection
2-48
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
2.3 Motor selection
The Motor Configuration Manuals are used to select the drive motors.
Reader’s note
Also refer to the References in the Appendix /PFK6,7/, /PFT5,6/, /PJAL/,
/PJFE/, /PJLM/, PJM/, /PJTM/, /PMS/, PPH/ and /PPM/!
The selection of the motor and the (brief) overload capability determines he size
(rating) of the power module (refer to Chapter 4).
A voltage protection module (VPM) is required for motors 1FE1 and 2SP1 with
an EMF > 800 V and maximum < 2 kV (> 565 V
eff
up to a maximum 1400 V
eff
).
When a fault condition develops, the VPM limits the DC link voltage at the drive
converter.
Technical data and ordering data, refer to 8.16.
Reader’s note
Reference: /PJFE/ Configuration Manual, 1FE1 Synchronous Built–in
Motors
/BU/ Catalog NC 60
/PMS/ Configuration Manual ECO Motor Spindles for
2SP1 Main Spindle Drives
Selection
VP module (VPM)
12.06
