11.2 Terminals
Table 11-2 Terminals for SIMODRIVE 611
Designation Terminal available in MLFB
X421 2–pin SIMODRIVE 611 universal HRS 6SY9907
X431 5–pin 6SY9908
X451, X452, X461, X462 10–pin 6SY9910
X461, X462 X453, X454 11–pin 6SY9913
X441 5–pin 6SY9911
X422, X432 8–pin 611 universal HRS option module terminals 6SY9912
Power connector, motor
connection
3–pin 6SY9904
Power connector, pulsed resistor 3–pin 6SY9905
X161, X171, X172 2–pin Module I/R, UI, monitoring module 6SY9433
X121 4–pin UI module 6SY9432
X111, X161, X431, X432 6–pin Module I/R, High Performance/High Standard module 6SY9896
X141 7–pin I/R module 6SY9898
X121, X431, X432 8–pin Module I/R, HLA/ANS module 6SY9897
X181 electronics power supply 8–pin I/R module 6SY9900
11.3 DC link covers
Damaged DC link covers must be replaced without delay!
Table 11-3 DC link cover
Designation Order Number
50 mm, DC link cover GWE–462018701000
100 mm, DC link cover GWE–462018701100
150 mm, DC link cover GWE–462018701201
300 mm, DC link cover GWE–462018701300
