Siemens SIMODRIVE 611 digital - System Overview

5
05.01
5.5 ”ANA module” control board
5-141
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
5.5.1 System overview
A complete 840D control with ANA module comprises various individual compo-
nents. These are listed below.
MCP
MMC CPU
Equipment bus
Battery and fan
slot
ANA
module
NCU
Digital I/O
(high–speed NC I/O)
Handwheel
(2x)
(1x of M)
Measurement (2x)
NCU box
PCMCIA
Machine control panel
Full CNC keyboard
ANA module
Operator panel
Cable distributor
ÄÄ
ÄÄ
Distributor box
HHU
Cable distributor
External 26.5 V supply (this is only
required when using terminals
PV1/MV1 or PV2/MV2)
Enable
BERO inputs
Line infeed
SITOP power
(external
power supply)
Note:
Shown for one analog axis
Analog sensors
Position sensing
0...10 V
Analog axis
NE
e.g. SIMATIC S7–300
NC CPU
Analog
drive amplifier
Analog axis
Fig. 5-11 System components
