6.3 Technical data
6-166
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
I/R
L1
L2
L3 PE
Q
to other fans
The motor protection
circuit–breaker Q is not included in
the scope of supply
M
Fan
U1 V1W1
I
n
 1.5 A
Observe the rotating field!
Fig. 6-10 Connection for 3–phase fans
Connection for
3–phase fans
