1
05.01
1.1 Overview of SIMODRIVE 611
1-25
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) -- 05/2008 Edition
For hydraulic linear axes (HLA/ANA)
S 2-- axis version
Motors
See Chapter 3
For 1PH/1PM/1LA or 1FT6/1FK/1FE1/2SP1 motors
S 2--axis version (with High--Standard control)
-- for motor encoders
-- additional measuring system, voltage signals
For 1FT6/1FK/1FN/1FW6--1PH/1FE1 motors
and induction motors
S 1--axis version (with resolver only)
S 2--axis version (resolver and motor encoder)
S Standard: analog setpoint interface
S Option modules: PROFIBUS DP or TERMINALS
Control units with digital setpoint interface
Control units with analog setpoint interface/PROFIBUS
1FN3
1FN1
1FT6
Control valve for hydraulic linear axes
(not included in the scope of supply)
1PH2
1PH4 1PH7
Induction motor,
e.g. 1LA
1FK6
Control units
See Chapter 5
1FK7
1PM
For 1FT6/1FK/1FN/1FW/1 PH/2SP1/1FE1/1PM motors
S 1--axis version (with High--Performance control)
-- for motor encoders
-- additional measuring system, voltage signals
S 2--axis version (with High--Performance control)
-- for motor encoders
-- additional measuring system, voltage signals
EnDat and SSI encoders
1FE1
1FW6
2SP1
Fig. 1-3 Overview of the drive system
1O
v
e
r
v
i
ew of
t
he D
r
i
v
eS
y
s
t
em10.04
