1.3 Engineering a drive
1-30
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
Table 1-1 Infeed modules
DC link power
P
ZK
[kW]
Peak power
[kW]
Infeed module
Order No.
Charge limit
[µF]
Infeed, unregulated
p5 10 6SN1146–1AB0j–0BAj 1200
p10 25 6SN1145–1AA0j–0AAj 6000
p28 50 6SN114j–1AA0j–0CAj 20000
Infeed/regenerative feedback module, regulated
p16 35 6SN114j–1BA0j–0BAj 20000
p36 70 6SN114j–1BA0j–0CAj 20000
p55 91 6SN114j–1Bj0j–0DAj 20000
p80 131 6SN114j–1BB0j–0EAj 20000
p120 175 6SN114j–1BA0j–0FAj 20000
