3
05.01
3.4 Direct position sensing
3-77
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
Red
Black
M5x12 max.
10.5 mm
Power supply
+ –
Fig. 3-8 Connection example for the High Performance digital control
Red
Black
M5x12 max.
10.5 mm
Power supply
+ –
Fig. 3-9 Connection example for the ”HLA module” control board
3 Motor Selection, Position/S
eed Sensin
10.04
