Materials used in the motor cooling circuit
The materials used in the cooling circuit must be coordinated with the materials in the motor.
Table 4-8 Materials used in the cooling circuit of the 1PH8 motor
Shaft height Bearing shield Pipes in the stator (designa‐
tion)
80 Cast iron (EN-GJL-200) Stainless steel
100 Cast iron (EN-GJL-200) Stainless steel
132 Cast iron (EN-GJL-200) Stainless steel
160 Cast iron (EN-GJL-200) Stainless steel
180 - Stainless steel (V4A)
225 - Stainless steel (V4A)
280 - Stainless steel (V4A)
Materials and components in the cooling circuit
The following table lists a wide variety of materials and components which may or may not be
used in a cooling circuit.
Table 4-9 Materials and components of a cooling circuit
Material Used as Description
Zinc Pipes, valves and
󹪝ttings
Use is not permitted.
Brass Pipes, valves and
󹪝ttings
Can be used in closed circuits with inhibitor.
Copper Pipes, valves and
󹪝ttings
Can be used only in closed circuits with inhibitors in which the heat
sink and copper component are separated (e.g. connection hose
on devices).
Common steel (e.g. St37) Pipes Permissible in closed circuits and semi-open circuits with inhibitors
or Antifrogen N, check for oxide formation, inspection window
recommended.
Cast steel, cast iron Pipes, motors Closed circuit and use of strainers and 󹪞ushback 󹪝lters. Fe separator
for stainless heat sink.
High-alloy steel, Group 1 (V2A) Pipes, valves and
󹪝ttings
Can be used for drinking or municipal water with a chloride content
up to <250ppm, suitable according to de󹪝nition in Section "Cool‐
ant de󹪝nition".
High-alloy steel, Group 2 (V4A) Pipes, valves and
󹪝ttings
Can be used for drinking or municipal water with a chloride content
up to <500ppm, suitable according to de󹪝nition in Section "Cool‐
ant de󹪝nition".
ABS (AcrylnitrileButadieneStyrene) Pipes, valves and
󹪝ttings
Suitable according to the de󹪝nition in Section "Coolant de󹪝nition".
Suitable for mixing with inhibitor and/or biocide as well as Antifro‐
gen N.
Installation comprising di󹪜erent ma‐
terials (mixed installation)
Pipes, valves and
󹪝ttings
Use is not permitted.
Mechanical properties
4.1Cooling
1PH8 SIMOTICS M main motors
Con󹪝guration Manual, 12/2022, A5E51895839A 73
