Configuration
5.4 Installation
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
117
If you fix the rotor and/or stator at both ends, this can result in significant material
deformation in the machine assembly due to thermal expansion, which could destroy the
motor.
• The machine must be designed in such a way that both the rotor and the stator are each
secured on one side only. See Chapter "Installation examples".
