1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
155
Technical data and characteristics
6
The technical data and characteristics for the 1FW6 Built-in torque motors are specified in
this Chapter. This data collection provides the motor data required for configuration and
contains a number of additional data for more detailed calculations for detailed analyses and
problem analyses. Technical data subject to change.
Note
System
-specific data refer to the combination of built-in torque motors 1FW6 with
SINAMICS
S120 drive systems.
Unless otherwise specified, the following boundary conditions ap
ply here:
The DC link voltage U
DC
is 600 V, the converter output voltage U
a max
is 425 V
The motor is water-cooled with the recommended minimum flow rate according to the
data sheet and a water intake temperature T
VORL
of 35 °C
The rated temperature of the motor winding T
N
is 130 °C
Voltages and currents are specified as rms values
Installation altitude of the motors up to 2000 m above sea level
For motors with integrated cooling that are equipped with main and precision coolers, the
power/performance data has been determined with the use of a cooling connection
adapter
6.1
Explanations of the formula abbreviations
Content of the data sheet
The data specified on the data sheets is explained in the following section. It is categorized
as follows:
Boundary conditions
Data at the rated operating point
Limit data
Physical constants
Data for the motor cooler
