1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
93
Note
Siemens offers its mechatronic support service
Please contact your local Siemens office if you require mechatronic support regarding,
the mechanical design of the machine
the closed-loop control technology to be used
the resolution and measuring accuracy of the encoder
the optimum integration of the encoder into the mechanical structure.
When designing, constructing and optimizing your mach
ine, we can support you with
-based and computer-based analyses.
You can obtain additional information from your Siemens contact person, also refer to the
Internet link in the introduction under "Technical Support".
Configuring software
5.1.1
SIZER configuration tool
Overview
The SIZER calculation tool supports you in the technical dimensioning of the hardware and
firmware components required for a drive task.
SIZER supports the following configuration steps:
● Configuring the power supply
● Designing the motor and gearbox, including calculation of mechanical transmission
elements
● Configuring the drive components
● Compiling the required accessories
● Selection of the line-side and motor-side power options
