Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
44 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
2.5.1.5
Ordering examples
Example 1:
Stator and rotor preassembled with transportation locks; cooling jacket; axial cable outlet for
SINAMICS S120 drive system, Motor Modules 18 A / 36 A:
Article number 1FW6090–0PB15–1JC2
Example 2:
Stator and rotor preassembled with transportation locks; integrated cooling; radial cable
outlet towards the outside for SINAMICS S120 drive system, Motor Modules 18 A / 36 A:
Article number 1FW6190–0VB07–1JC2
Example 3:
Cooling connection adapter (axial/radial) for sizes 1FW616, 1FW619, and 1FW623:
Article number 1FW6160–1BA00–0AA0
Example 4:
Individual component/stator as spare part: Article number 1FW6190–8VB07–1JD2
Individual component/rotor as spare part: Article number 1FW6190–8RA07–0AA0
Individual component/spare part round sealing ring: Article number 1FW6090–1EA00–0AA0
(for size 1FW609x)
2.5.2
Selection and ordering data 1FW6
Note
Overview of important motor data
A selection of important motor data and dimensions is provided in this chapter. You can find
all of the data in Chapter "
Technical data and characteristics (Page 155)" – and in Chapter
"
Installation drawings/dimension sheets (Page 519)".
