Siemens SIMOTICS T-1FW6 Configuration Manual

Configuration
5.4 Installation
1FW6 Built-in torque motors
128 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
Table 5- 7 Maximum permissible screw insertion depths for the stator and rotor
Component
Max. permissible screw-in depth
in mm
Thread
1FW605, 1FW606 / stator
8.5 + section without thread *)
M6
1FW605, 1FW606 / rotor 11 M6
1FW609, 1FW613 / stator and rotor
10
M5
1FW615 / stator and rotor
12
M6
1FW616, 1FW619, 1FW623 / stator
13
M8
1FW616, 1FW619, 1FW623 / rotor
12
M8
1FW629 / stator
15
M10
1FW629 / rotor
15
M10
*) See the installation drawing "detail Z"
5.4.6
Procedure when installing the motor
Sequence for installing the motor
WARNING
Risk of injury and material damage
Injury and/or destruction of motor components can occur if you do not observe the specified
sequence when installing the motor.
• Perform work steps in the specified sequence during installation.
