Siemens SIMOTICS T-1FW6 - 2 Description of the Motor

1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
23
Description of the motor
2
1FW6 built-in torque motor
Figure 2-1 1FW6 built-in torque motors with cooling jacket (left) and with integrated cooling (right)
