Siemens SIMOTICS T-1FW6 Configuration Manual

Coupled motors
10.3 Machine design and adjustment of the phase angle
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
541
Power connection
Table 10- 1 Power connection when two torque motors are operated in parallel
Motor Module
Master
Stoker
Tandem arrangement
Stoker
Janus arrangement
U2
U
U
U
V2 V V W
W2
W
W
V
10.3
Machine design and adjustment of the phase angle
Each rotation of the mounted rotor induces the 3-phase EMF of the motor in the stator phase
windings. When the master and stoker operate in parallel, the phase angle of each stoker
EMF must match the phase angle of the master EMF.
To adjust the phase angle, the stator and rotor each have a reference mark on their face
sides. The reference marks of the motors are shown in Chapter "Installation
drawings/Dimension drawings (Page 519)".
● The reference mark in the stator depends on the motor article number.
– 1FW6050-xxBxx-0Fxx, 1FW6060-xxBxx-0Kxx:
engraved with the letter V
– 1FW6050-xxBxx-0Kxx, 1FW6050-xxBxx-1Jxx, 1FW6060-xxBxx-1Jxx:
Engraved with the letter Y
– 1FW6090-xxBxx-xxxx to 1FW6150-xxBxx-xxxx:
centering bore
– 1FW6160-xxBxx-xxxx to 1FW6290-xxBxx-xxxx:
Notch
● The reference mark in the rotor is a centering bore without thread.
