Electrical connection
8.3 System integration
1FW6 Built-in torque motors
506 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
8.3.6
Data for the power cable at the stator
Table 8- 4 Data for the power cable at the stator
Motor type
Max. diameter
"d1" in mm
1
)
No. of cores x cross-
section in mm
2
Min. bending radius
"R1" in mm
1
)
Max. height of
sleeve "C1" in mm
Connector
size
2
)
1FW6050-xxB03-0Fxx
11
4x2.5
44
18
1
1FW6050-xxB05-0Fxx
11
4x2.5
44
18
1
1FW6050-xxB07-0Fxx
11
4x2.5
44
18
1
1FW6050-xxB07-0Kxx
11
4x2.5
44
18
1
1FW6050-xxB10-0Kxx
11
4x2.5
44
18
1
1FW6050-xxB15-0Kxx
11
4x2.5
44
18
1
1FW6050-xxB15-1Jxx
11
4x2.5
44
18
1
1FW6060-xxB03-0Fxx
11
4x2.5
44
18
1
1FW6060-xxB05-0Fxx
11
4x2.5
44
18
1
1FW6060-xxB05-0Kxx
11
4x2.5
44
18
1
1FW6060-xxB07-0Fxx
11
4x2.5
44
18
1
1FW6060-xxB07-0Kxx
11
4x2.5
44
18
1
1FW6060-xxB10-0Kxx
11
4x2.5
44
18
1
1FW6060-xxB10-1Jxx
11
4x2.5
44
18
1
1FW6060-xxB15-0Kxx
11
4x2.5
44
18
1
1FW6060-xxB15-1Jxx
11
4x2.5
44
18
1
1FW6090-xxB05-0Fxx
11
4x2.5
44
18
1
1FW6090-xxB05-0Kxx
11
4x2.5
44
18
1
1FW6090-xxB07-0Kxx
11
4x2.5
44
18
1
1FW6090-xxB07-1Jxx
11
4x2.5
44
18
1
1FW6090-xxB10-0Kxx
11
4x2.5
44
18
1
1FW6090-xxB10-1Jxx
11
4x2.5
44
18
1
1FW6090-xxB15-1Jxx
11
4x2.5
44
18
1
1FW6090-xxB15-2Jxx
12.3
4x4.0
49.2
23
1.5
1FW6130-xxB05-0Kxx 11 4x2.5 44 18 1
1FW6130-xxB05-1Jxx 11 4x2.5 44 18 1
1FW6130-xxB07-0Kxx
11
4x2.5
44
18
1
1FW6130-xxB07-1Jxx
11
4x2.5
44
18
1
1FW6130-xxB10-1Jxx
11
4x2.5
44
18
1
1FW6130-xxB10-2Jxx
12.3
4x4.0
49.2
23
1.5
1FW6130-xxB15-1Jxx
11
4x2.5
44
18
1
1FW6130-xxB15-2Jxx
12.3
4x4.0
49.2
23
1.5
1FW6150-xxB05-1Jxx
11
4x2.5
44
18
1
1FW6150-xxB05-4Fxx
18.2
4x10.0
72.8
29
1.5
1FW6150-xxB07-2Jxx
12.3
4x4.0
49.2
23
1.5
1FW6150-xxB07-4Fxx
18.2
4x10.0
72.8
29
1.5
