Siemens SIMOTICS T-1FW6 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
45
Table 2- 6 Built-in torque motors: overview (part 1 of 2)
Order desig. /
Size
Rated torque
1)
M
N
in Nm
Max. torque
M
MAX
in Nm
Rated cur-
rent
1)
I
N
in A
Max. current
I
MAX
in A
Rated speed
2)
n
N
in rpm
Max. speed at
max. torque
2)
n
MAX,MMAX
in rpm
1FW6050-xxB03-0Fxx
23.2
34.4
4.87
7.61
940
697
1FW6050-xxB05-0Fxx
39.5
57.5
4.98
7.64
525
376
1FW6050-xxB07-0Fxx
55.7
80.6
5.02
7.65
349
236
1FW6050-xxB07-0Kxx
50.9
81.2
9
14.6
895
685
1FW6050-xxB10-0Kxx
73.7
116
9.13
14.6
589
437
1FW6050-xxB15-0Kxx
112
174
9.23
14.6
348
234
1FW6050-xxB15-1Jxx
109
174
18
29.1
850
658
1FW6060-xxB03-0Fxx
32
64.5
4.33
9.81
633
330
1FW6060-xxB05-0Fxx
62
123
4.42
9.85
309
126
1FW6060-xxB05-0Kxx
60.6
123
7.79
17.7
663
399
1FW6060-xxB07-0Fxx
84.3
166
4.45
9.86
203
43.3
1FW6060-xxB07-0Kxx
83
166
7.9
17.8
464
256
1FW6060-xxB10-0Kxx
117
231
7.98
17.8
302
133
1FW6060-xxB10-1Jxx
111
226
14.6
31.5
708
471
1FW6060-xxB15-0Kxx
172
339
8.04
17.8
174
27.6
1FW6060-xxB15-1Jxx
166
332
14.8
31.5
442
260
1FW6090-xxB05-0Fxx
113
179
5.62
9.55
142
50.2
1FW6090-xxB05-0Kxx
109
179
7.47
13.3
250
142
1FW6090-xxB07-0Kxx
154
251
9.52
16.7
224
128
1FW6090-xxB07-1Jxx
142
251
13.9
26.5
428
278
1FW6090-xxB10-0Kxx
231
358
7.97
13.3
83.9
12.4
1FW6090-xxB10-1Jxx
216
358
14.8
26.6
272
170
1FW6090-xxB15-1Jxx
338
537
15.5
26.6
154
80.6
1FW6090-xxB15-2Jxx
319
537
23.8
43.4
312
202
1FW6130-xxB05-0Kxx 241 439 9.06 18.1 132 46.5
1FW6130-xxB05-1Jxx 217 439 14.5 32.3 308 181
1FW6130-xxB07-0Kxx
344
614
10.4
20.3
96.1
21.5
1FW6130-xxB07-1Jxx
324
614
15.5
32.3
201
109
1FW6130-xxB10-1Jxx
484
878
16.2
32.3
123
50.9
1FW6130-xxB10-2Jxx
449
878
24.7
53.1
249
148
1FW6130-xxB15-1Jxx
743
1320
18.7
36.2
78.4
16
1FW6130-xxB15-2Jxx
714
1320
26.9
54.3
152
78.8
1FW6150-xxB05-1Jxx
338
710
17.2
44.1
234
108
1FW6150-xxB05-4Fxx
298
710
36.2
106
654
332
1FW6150-xxB07-2Jxx
470
994
25.6
66.1
259
126
