Siemens SIMOTICS T-1FW6 Configuration Manual

Description of the motor
2.5 Selection and ordering data
1FW6 Built-in torque motors
46 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
Order desig. /
Size
Rated torque
1)
M
N
in Nm
Max. torque
M
MAX
in Nm
Rated cur-
rent
1)
I
N
in A
Max. current
I
MAX
in A
Rated speed
2)
n
N
in rpm
Max. speed at
max. torque
2)
n
MAX,MMAX
in rpm
1FW6150-xxB07-4Fxx
444
994
38.7
106
449
230
1FW6150-xxB10-2Jxx
688
1420
26.3
66.1
171
75.9
1FW6150-xxB10-4Fxx
663
1420
40.5
106
301
152
1FW6150-xxB15-2Jxx
1050
2130
26.8
66.1
103
33.1
1FW6150-xxB15-4Fxx
1030
2130
41.9
106
188
89.1
1FW6160-xxB05-1Jxx
432
716
16.5
31.6
140
80.6
1FW6160-xxB05-2Jxx
405
716
24.1
49.4
242
142
1FW6160-xxB05-5Gxx
317
716
37.4
98.8
574
308
1FW6160-xxB07-1Jxx
621
1000
17
31.6
93.5
51.7
1FW6160-xxB07-2Jxx
596
1000
25.4
49.4
164
97.2
1FW6160-xxB07-5Gxx
517
1000
43.7
98.8
379
218
1FW6160-xxB07-8Fxx
436
1000
52.4
141
594
320
1FW6160-xxB10-1Jxx
904
1430
17.3
31.6
59
28.5
1FW6160-xxB10-2Jxx
880
1430
26.3
49.4
108
62.4
1FW6160-xxB10-5Gxx
807
1430
48
98.8
250
149
1FW6160-xxB10-8Fxx
737
1430
62.3
141
383
221
1FW6160-xxB10-2Pxx
629
1430
74
198
584
317
1FW6160-xxB15-2Jxx
1350
2150
27
49.4
64.6
33.8
1FW6160-xxB15-5Gxx
1280
2150
51.1
98.8
156
93.8
1FW6160-xxB15-8Fxx
1220
2150
69.1
141
237
142
1FW6160-xxB15-2Pxx
1130
2150
89
198
355
208
1FW6160-xxB15-0Wxx
970
2150
109
282
551
304
1FW6160-xxB20-5Gxx
1760
2860
52.5
98.8
111
65.5
1FW6160-xxB20-8Fxx
1700
2860
72.3
141
170
103
1FW6160-xxB20-2Pxx 1610 2860 95.7 198 253 152
1FW6160-xxB20-0Wxx 1470 2860 124 282 387 225
1FW6190-xxB05-1Jxx
634
990
17
31.8
92.7
51.7
1FW6190-xxB05-2Jxx
608
990
24.4
47.7
155
91
1FW6190-xxB05-5Gxx
516
990
40.8
95.3
364
204
1FW6190-xxB07-1Jxx
907
1390
17.5
31.8
61
31.2
1FW6190-xxB07-2Jxx
881
1390
25.3
47.7
105
60.8
1FW6190-xxB07-5Gxx
798
1390
45.4
95.3
244
143
1FW6190-xxB07-8Fxx
714
1390
57.5
136
377
212
1FW6190-xxB10-1Jxx
1310
1980
17.8
31.8
37.2
14.2
1FW6190-xxB10-2Jxx
1290
1980
26.1
47.7
67.6
37.1
1FW6190-xxB10-5Gxx
1210
1980
48.5
95.3
161
96.6
