Data sheet 1FW6050-xxB05-xxxx
Table 6- 3 1FW6050-xxB05-0Fxx
Technical data
1FW6050
Symbol
Unit
-xxB05-0Fxx
Boundary conditions
DC link voltage
U
DC
V
600
Water cooling inlet temperature
T
VORL
°C
35
Rated temperature of winding
T
N
°C
130
Data at the rated operating point
Rated torque
M
N
Nm
39.5
Rated current
I
N
A
4.98
Rated speed
n
N
rpm
525
Rated power loss
P
V,N
kW
1.04
Limit data
Maximum torque
M
MAX
Nm
57.5
Maximum current
I
MAX
A
7.64
Electric motor power at M
MAX
P
EL,MAX
kW
4.59
Maximum speed
n
MAX
rpm
1730
Maximum speed at maximum torque
n
MAX,MMAX
rpm
376
Max. speed without VPM
n
MAX,INV
rpm
1180
No-load speed
n
MAX,0
rpm
865
Torque at n = 1 rpm
M
0
Nm
40.4
Current at M
0
and n = 1 rpm
I
0
A
5.1
Thermal static torque
M
0
*
Nm
29
Thermal stall current
I
0
*
A
3.6
Physical constants
Torque constant at 20 °C
k
T,20
Nm/A
8.11
Voltage constant
k
E
V/(1000/min)
491
Motor constant at 20 °C k
M,20
Nm/(W)
0,5
1.54
Thermal time constant t
TH
s 75
No. of pole pairs
p
-
11
Cogging torque
M
COG
Nm
0.596
Stator mass
m
S
kg
4.2
Rotor mass
m
L
kg
1.69
Rotor moment of inertia
J
L
10
-2
kgm
2
0.267
Phase resistance of winding at 20 °C
R
STR, 20
Ω
9.29
Phase inductance of winding
L
STR
mH
39.1
