Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
293
Technical data
1FW6160
Symbol
Unit
-xxB05-1Jxx
-xxB05-2Jxx
-xxB05-5Gxx
Data for main motor cooler *)
Maximum dissipated thermal power
Q
H,MAX
kW
2.21
2.22
2.25
Recommended minimum volume flow
H,MIN
l/min
3.84
3.84
3.84
Cooling medium temperature increase
ΔT
H
K
8.28
8.32
8.42
Pressure drop
Δp
H
bar
0.279
0.279
0.279
Data for precision motor cooler *)
Maximum dissipated thermal power
Q
P,MAX
kW
0.238
0.239
0.242
Recommended minimum volume flow
P,MIN
l/min
1.46
1.46
1.46
Cooling medium temperature increase
ΔT
P
K
2.35
2.36
2.38
Pressure drop
Δp
P
bar
0.279
0.279
0.279
*) Parallel connection of main and precision motor cooler
