Description of the motor
2.3 Technical features and ambient conditions
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
35
Technical feature
Version
Insulating material class of stator
winding according to EN 60034-1
Temperature class 155 (F)
Impulse withstand voltage
insulation class according to
EN 60034-18-41
(IEC 60034-18-41)
IVIC: C
Magnet material
Rare earth material
Connection, electrical Cable outlet:
axial
radial outward (not for 1FW605 and 1FW606)
tangential (not in the case of motors with individual conductors)
Connection type:
Permanently connected power and signal cables with open core
ends
Length: 2 m
Permanently connected power cables with single cores and
signal cables with open core ends
Length: 1 m
Permanently connected power and signal cables pre-assembled
with connectors (not in the case of motors with single cores)
Length: 0.5 m
Motor feeder cables For the specifications of the motor feeder cables, see Chapter
"Requirements for the motor supply cables (Page 516)"
Torque ripple
≤ 1.5% M
0
