Siemens SIMOTICS T-1FW6 Configuration Manual

Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
391
Technical data
1FW6230
Symbol
Unit
-xxB05-1Jxx
-xxB05-2Jxx
-xxB05-5Gxx
Data for main motor cooler *)
Maximum dissipated thermal power
Q
H,MAX
kW
2.75
2.84
2.78
Recommended minimum volume flow
H,MIN
l/min
4.79
4.79
4.79
Cooling medium temperature increase
ΔT
H
K
8.26
8.52
8.34
Pressure drop
Δp
H
bar
0.459
0.459
0.459
Data for precision motor cooler *)
Maximum dissipated thermal power
Q
P,MAX
kW
0.297
0.306
0.299
Recommended minimum volume flow
P,MIN
l/min
1.61
1.61
1.61
Cooling medium temperature increase
ΔT
P
K
2.65
2.73
2.67
Pressure drop
Δp
P
bar
0.459
0.459
0.459
*) Parallel connection of main and precision motor cooler
