Siemens SIMOTICS T-1FW6 Configuration Manual

Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
429
Technical data
1FW6230
Symbol
Unit
-xxB20-5Gxx
-xxB20-8Fxx
-xxB20-2Pxx
Data for main motor cooler *)
Maximum dissipated thermal power
Q
H,MAX
kW
8.11
8.14
8.34
Recommended minimum volume flow
H,MIN
l/min
13
13
13
Cooling medium temperature increase
ΔT
H
K
8.95
8.98
9.2
Pressure drop
Δp
H
bar
3.39
3.39
3.39
Data for precision motor cooler *)
Maximum dissipated thermal power
Q
P,MAX
kW
0.874
0.878
0.899
Recommended minimum volume flow
P,MIN
l/min
5.09
5.09
5.09
Cooling medium temperature increase
ΔT
P
K
2.47
2.48
2.54
Pressure drop
Δp
P
bar
3.39
3.39
3.39
*) Parallel connection of main and precision motor cooler
