Siemens SIMOTICS T-1FW6 Configuration Manual

Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
439
Technical data
1FW6290
Symbol
Unit
-xxB07-5Gxx
-xxB07-0Lxx
-xxB07-2Pxx
Data for main motor cooler *)
Maximum dissipated thermal power
Q
H,MAX
kW
3.87
3.86
3.89
Recommended minimum volume flow
H,MIN
l/min
5.78
5.78
5.78
Cooling medium temperature increase
ΔT
H
K
9.63
9.6
9.68
Pressure drop
Δp
H
bar
0.358
0.358
0.358
Data for precision motor cooler *)
Maximum dissipated thermal power
Q
P,MAX
kW
0.417
0.416
0.42
Recommended minimum volume flow
P,MIN
l/min
2.22
2.22
2.22
Cooling medium temperature increase
ΔT
P
K
2.7
2.69
2.72
Pressure drop
Δp
P
bar
0.358
0.358
0.358
*) Parallel connection of main and precision motor cooler
