Mechanical properties
3.1 Cooling
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
55
Materials used in the cooling circuits of torque motors
Table 3- 1 Materials in the cooling circuits of torque motors (not including the material used for the connections)
Cooling jacket
for
1FW609, 1FW613 and
1FW615
Integrated cooling (main
cooler) for
1FW605, 1FW606 and
1FW616 up to 1FW629
Integrated cooling (precision
cooler) for
1FW616 to 1FW629
Cooling connection adapter
for
1FW616 to 1FW629
1FW609, 1FW613:
• EN AW-5083
(EN 573-3)
• Viton® (FPM) gasket
1FW615:
• S355J2G3
(EN 10025)
• Viton® (FPM) gasket
1FW605, 1FW606:
• X10CrNiS18-9
(DIN 17440)
• SF-Cu
(DIN 17671)
• Viton® (FPM) gasket
1FW616 to 1FW629:
• X6CrNiTi18-10
(EN 10088)
• SF-Cu
(DIN 17671)
• CW617N
(EN 12449 / EN 12167)
• Viton® (FPM) gasket
• Ag 102
(EN 1045) +
welding flux EN 1045-
FH10
• X6CrNiTi18-10
(EN 10088)
• SF-Cu
(DIN 17671)
• CW617N
(EN 12449)
• Viton® (FPM) gasket
• CW617N
(EN 12449)
• Viton® (FPM) gasket
NOTICE
Corrosion as a result of unsuitable materials used to connect the cooler
Corrosion damage can occur if you use unsuitable materials to connect to the cooler.
• We recommend that you use brass or stainless steel fittings when connecting the
cooler.
