Motor components and options
4.1 Motor components
1FW6 Built-in torque motors
76 Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
Table 4- 2 Types of temperature monitoring circuits
Article No.
Temp-S (PTC 130 °C),
Temp-F (KTY 84)
Temp-S (PTC 130 °C),
Temp-F (Pt1000)
Temp-S (PTC 130 °C and
PTC 150 °C),
Temp-F (KTY 84)
1FW6050-xxxxx-xxx1
X
1FW6050-xxxxx-xxx3 X
1FW6060-xxxxx-xxx1
X
1FW6060-xxxxx-xxx3 X
1FW6090-xxxxx-xxx2
X
1FW6090-xxxxx-xxx3
X
1FW6130-xxxxx-xxx2
X
1FW6130-xxxxx-xxx3
X
1FW6150-xxxxx-xxx2
X
1FW6150-xxxxx-xxx3
X
1FW6160-xxxxx-xxx2
X
1FW6160-xxxxx-xxx3
X
1FW6190-xxxxx-xxx2
X
1FW6190-xxxxx-xxx3
X
1FW6230-xxxxx-xxx2
X
1FW6230-xxxxx-xxx3
X
1FW6290-xxxxx-xxx2
X
1FW6290-xxxxx-xxx3
X
Every phase winding is monitored so that also uneven currents and therefore the
associated different thermal loads of the individual phase windings are detected. For the
following motion and/or operating states, the individual phase windings have different
thermal loads, while the motor simultaneously outputs a torque:
At standstill (holding)
When rotating very slowly
Oscillation through a very small angle
Note
Shutdown time
If Temp
-
S responds, and its response threshold is not undershot again in the meantime, then
the drive system must shut down (de
-energize) the motor within 2 seconds. This prevents
the motor windings from becoming inadmissibly hot.
