Siemens SINUMERIK 808D User Manual

Programming and Operating Manual (Milling)
330 6FC5398-4DP10-0BA6, 09/2017
Address
Significance
Value assignments
Information
Programming
G153 Non-modal skipping of the settable work
offset including base frame
G60 * Exact stop 10: Approach behavior, mo-
dally effective
G64 Continuous-path mode
G62
Corner deceleration at inside corners when
tool radius offset is active (G41, G42)
Only in conjunction with con-
tinuous-path mode
G62 Z... G1
G9
Non-modal exact stop
11: Exact stop, non-modal
G601 *
Exact stop window, fine, with G60, G9
12: Exact stop window, modal-
ly effective
G602 Exact stop window, coarse, with G60, G9
G621 Corner deceleration at all corners Only in conjunction with con-
tinuous-path mode.
G621 AIDS=...
G70
Inch dimension data input
13: Inch/metric dimension
input, modally effective
G71 *
Metric dimension data input
G700 Inch dimension data input; also for
feedrate F
G710 Metric dimension data input; also for
feedrate F
G90 *
Absolute dimension data input
14: Absolute/incremental di-
mension, modally effective
G91 Incremental dimension data input
G94 * Feed F in mm/min 15: Feedrate/spindle, modally
effective
G95
Feedrate F in mm/spindle revolutions
CFC * Feedrate override with circle ON 16: Feed override, modally
effective
CFTCP Feedrate override OFF
G450 *
Transition circle
18: Behavior at corners when
working with tool radius com-
pensation, modally effective
G451 Point of intersection
BRISK * Jerking path acceleration 21: Acceleration profile, mo-
dally effective
SOFT
Jerk-limited path acceleration
FFWOF *
Feedforward control OFF
24: Feedforward control, mo-
dally effective
FFWON
Feedforward control ON
EXTCALL
Execute external subprogram
Reload program from HMI in
"Execution from external
source" mode.
G340 * Approach and retraction in space (SAR) 44: Path segmentation with
SAR, modally effective
G341
Approach and retraction in the plane (SAR)
G290 *
SIEMENS mode
47: External NC languages,
modally effective
G291 External mode
H
H0=
to
H9999=
H function ± 0.0000001 ...
9999 9999
(8 decimal places)
or with specification
of an exponent:
± (10
-300
... 10
+300
)
Value transfer to the PLC;
meaning defined by the ma-
chine manufacturer
H0=... H9999=...
e.g.: H7=23.456
I Interpolation param-
eters
±0.001 ... 99
999.999
Thread:
0.001 ... 2000.000
Belongs to the X axis; mean-
ing dependent on G2, G3 -
>circle center or G33, G331,
G332 -> thread pitch
See G2, G3, G33, G331 and
G332
